100W 1390 CO2 laser machine for non-metal
Video show
Product introduction
CO2 laser cutting machine is a cutting equipment used in industrial production. It is widely used in cutting and engraving various non-metallic materials, such as wood, acrylic, plywood, MDF, plastic, leather and so on. You can cut and engrave materials with different thicknesses by selecting different powers. Usually the wattage range of the laser machine is 60W-300W, and the thickness accuracy of cutting and engraving can range from 0.02 mm to 20 mm. The cutting format can be specifically selected according to your needs, generally there are 6040, 9060, 1390, 1325, 1610, 1810, 1530 and other models to choose from. The cutting method of this machine is high in precision, the effect is fine, the cutting effect is smooth and burr-free; the CO2 glass tube is used, the energy is concentrated and stable, and can work continuously; the laser tube has a long life, can achieve long-term work, and has low cost.
Product parameter and specification
Model | USJ-1390 |
Working size | 1300mm*900mm |
Cooling type | Water cooling |
Table type | Blade or Honeycomb table |
Controlllor | RD6445G control system |
Laser power | 100W |
Laser type | CO2 Laser Tube |
Laser tube | Beijing EFR / RECI optional |
Drive System | Leadshine driving system and stepper motor |
Guide Rails | Taiwan Hiwin Square Linear Rail |
Belt | Shanghai fulong belt |
Water chiller | CW5000 |
Lens | Singapore lens and mirrors |
Assist device | exhaust fan,air pump,water chiller |
Optional parts | Up-down work table,rotary system,red light pointer |
Interface | USB |
Command | G code*.u00*.mmg*pl |
Product feature and application
● Compared with the traditional cutting method, the CO2 laser cutting machine has higher precision and exquisite effect. Because laser cutting belongs to high temperature processing, there is no need to process the cutting surface again.
● The CO2 laser cutting machine is a non-physical working method and does not make contact with the processed parts, so the processed object does not need to have a complicated tooling structure.
● The machine adopts CO2 glass tube, energy is concentrated and stable, and it can work continuously. ● The machine is suitable for the cutting industry of plastic products. It can be processed continuously and can be used with loading and unloading robots to realize automatic production.
● The use cost is low, the life of a laser tube of this machine is about 4000-7000H, and the stability can be continuously guaranteed during use.
● The machine supports cutting and marking at one time, without secondary processing, and can support multiple layer processing techniques.
● The software supports a variety of vector graphics such as AI, DXF, PLT, and is compatible with image formats.
● The equipment has optional processing bottom plates such as honeycomb panel, knife strip aluminum, tooling positioning, etc., to ensure the effect of cutting.
It is suitable for non-metal industries such as the cutting of injection parts, leather, cloth, epoxy resin, wood products, paper, acrylic, plush, plastic, rubber, bamboo products and so on.
Production details
1.Newest Ruida 6445G control card,color touch screen,support multi language,like English,Russia etc.Support offline working.
2.Multi function laser head,high presicion and durable.
3.Taiwan HIWIN guide rails,strong load-bearing capacity and long life.
4.The best RECI brand laser tube,have longer service life.
5.Clean electrical box,installed by professional technician.
6.Optional blade worktable and honeycomb worktable,suitable for cuting hard materials and soft materials.
CE certification
Sample pictures
Our factory
Packing and Shipping
Our service
1. We provide 24 months warranty for the machine. Machine as normal using
and maintenance condition, if get any problem, will provide spare parts for free.
2.We would deal with all the production and shipping affairs,
after everything is ready, we would tell you everything goes well here.
3. Our engineer could provide technology support and training for you in your country,
If your machine has big problems if by any chance, our engineers would arrive there to debug and fix.
4. Our engineer could service for you 24 hours online, by Whatsapp,Wechat,
or by cellphone etc.we would pay their 100% time and energy to solve your problems!
FAQ
1.How long about the machine's guarantee?
2 years.
2.How about your after-sales service?
Technical support by phone,Whatsapp,Skype,e-mail or QQ around the clock.
3.Are you factory or trading company?
We are factory and found in 2002.
We have strong research team and development with production workshop.
You are welcomed to come to our factory at any time.
4.Do you arrange shipment for the machines?
Yes,for FOB or CIFprice,we will arrange shipment for you,for EXW price ,
clients need to arrange shipment by themselves or thier agent.
