What is Steel pipe cutter machine ?
1>It's professional tube cutting fiber laser machine, suitable for all kinds of stainless tube, round tube, square tube and oval tube. Improve the quality of tube cutting products, make cutting become simple.
2>Apply industry
Suitable for all kinds of metal pipes: round pipe, square pipe, rectangular pipe, elliptical pipe, waist pipe, D pipe, hexagonal pipe, special-shaped pipe, etc
Compared with the traditional processing technology, the advantages of metal laser pipe cutting machine
More widely used
The cutting quality, effect and cost of metal laser pipe cutting machine have been greatly improved compared with traditional processing methods or processes. Many industries have been widely used, metal laser pipe cutting machine can be used for surface cutting, drilling, engraving to meet the cutting needs of customers personalized development. You only need to draw any graphics at will through the computer, you can complete a variety of complex fancy pattern cutting.
Higher precision
Compared with the traditional cutting method, the metal laser pipe cutting machine not only has high speed, low consumption, but also has no mechanical stress on the pipe fitting, so the effect, accuracy and cutting speed of the cutting product are very good. In recent years, the development of metal laser pipe cutting machine is very fast, in the office furniture, sports equipment, building hardware, advertising signs, lighting and other industries have gradually replaced the traditional process, and become the standard of metal materials processing in these industries.
More efficient
Compared with the traditional cutting technology, the laser pipe cutting machine has better processing quality, smoother cutting section of the pipe after processing, and the pipe after cutting can be directly used in the next process, reducing the processing process and saving costs. Compared with the traditional pipe processing that requires cutting, blanking and bending, the traditional pipe processing consumes a large number of molds, and the laser cutting of the pipe is not only a few processes, high efficiency, one step in place, but also a good cutting quality
Detailed configuration of laser pipe cutting machine
laser head
Raytools BM110 Autofocus cutting head
The surrounding parts of the focus are cooled by full-circulation water. In the case of high-power cutting, small-volume cutting and long-term cutting, it can achieve no heat and no fog, and the service life of the cutting head is greatly improved.
Max laser source
-Long life, maintenance-free operation
- High electro-optic conversion efficiency
- Good beam quality, high energy density
- Remote network diagnosis system
- wide modulation frequency
- Strong reliability
FUSCUT 3000S controller
The FSCUT3000S system is designed for pipe cutting control, supporting high precision in the production of standard pipes (mesh, round, oval, oval, and round, etc.), free-form and channel steel (T/U/H/L shapes) and high efficiency.
3D pipe layout software TubesT
TubesT is a 3D tube typesetting software designed for CypTube/TubePro laser cutting systems. From part drawing and modification, to full type compensation, strategy layout, to report generation, TubesT will meet and exceed your production needs.
Japanese Fuji servo motor and driver
- Closed-loop control, no out-of-step, high precision.
- Good high-speed performance, the rated speed can generally reach 3000 rpm.
- Smooth operation even at low speeds.
- Fast response time and high reliability.
Integrated machine bed
The unique industrial structure design gives it maximum stability and higher shock resistance and shock absorption qualities
Taiwan YYC rack and pinion
-High transmission efficiency
- Transmission is sensitive and stable
- High positioning accuracy
- Good accuracy retention
- High transmission rigidity
Japan Shimpo reducer
- High output torque, small rotation clearance
-PCS-2 standard configuration, the efficiency is as high as 98%.
- High gear meshing precision
hanli water chiller
- Real-time display of current water temperature
- Dual temperature dual control mode
- Energy saving, electricity saving, environmental protection
- Stable and reliable performance
Automatic oil supply lubrication device
We can control the time and frequency of lubrication through the central control system. It can lubricate sliders, guide rails, racks, etc., and can automatically collect used lubricating oil. It has the functions of abnormal lubrication alarm and low liquid level alarm to help maintain the fiber laser cutting machine.
Pneumatic proportional valve of Aventics GMBH
Air flow and pressure can be continuously proportionally adjusted according to changes in the input signal
French Schneider Electric components
- Flame retardant casing, environmentally friendly.
- 3C certification.
- Quick shutdown function.
- Stable and not easily affected by seasonal temperatures.
Handle operation control
Magnetic design for easy access anytime. The handle allows you to control the machine from different angles for easy operation. One-button wireless control for calibrating, blowing, simulating, cutting, pausing and more.
Smart touch screen
- Adopt HD tempered glass, smart touch, fast response, smoother operation.
- Ultra-low power consumption and high resolution.
High power dual exhaust fan system
Dual high power exhaust fans provide powerful suction
Structure and Aging Treatment
In order to ensure high precision, each device will undergo fine milling and high-temperature aging treatment, and the structure will not be deformed after long-term use.
Optional configuration
Technical parameter
|
Model |
UN-220G6 ( Pipe Fiber Laser Tube Cutting Machine) |
|
Machine Structure |
All-in-one machine bed |
|
Gantry |
Aero-grade tensile cast aluminum beam |
|
Cutting diameter |
220mm |
| Cutting length | 6m |
|
Fiber laser power |
Max 3000W |
|
Connector |
USB,RJ45 |
|
Travelling speed |
80m/min |
|
Position accuracy/repeatability accuracy |
0.02mm/m / 0.02mm |
|
maximum acceleration |
1G |
|
working voltage |
380V,3 PHASE/60HZ( Also can make customized) |
|
Brands of motors and drives |
Japan Fuji servo motor and drivers |
|
launching system |
Double rack and pinion types |
|
control system |
FUSCUT 3000S Controller |
|
Cutting Head |
Raytools BM110 Autofocus cutting head |
|
Reducer |
Japan Shimpo |
|
Rail Guide |
Taiwan Hiwin Rail Guide |
|
Rack |
Taiwan YYC |
|
electrical element |
Schneider of France |
|
Water cooling system |
Hanli |
|
Computer |
Industry computer |
|
self-lubrication system |
Yes |
samples
Jinan Unistar Machinery Co., Ltd. was established in 2002, experienced 15 years of development and solid operation, the company has 20 professional research senior technical engineers in the field of laser, 100 sales team, 30 domestic and foreign after-sales service team, 150 workers, with strong new product development ability, Has developed into one of the largest and most influential enterprises in the laser industry
UNISTAR Laser intelligent equipment are mainly include sheet metal fiber laser cutting machine ,Tube metal cutting machine , Sheet metal and tube fiber laser cutting machine ,small Fiber laser cutter, high power cnc fiber laser cutter , laser cutting fiber , handheld fiber laser welding machine , Laser cleaning machine , 3 in1 fiber laser machine . cnc bending machine so on . Our equipment have been sold to Saudi Arabia, Bangladesh, Bulgaria, Serbia, Spain, UK, Poland , Hungary, Italy, South Korea, Ethiopia, Lebanon, Jordan, Egypt, Syria, Yemen, Russia, Australia, Canada etc more than 120 countries and regions , Which are highly recognized and appreciated by customers. Excellent quality, reliable price, perfect service is the value and mission of Unistar Company.
After Sales Service and Warranty
1> The machine warranty 2 years
2> 20 sets consumable parts Nozzle free ,10 sets protect lens free
3> a> During the warranty period, in case of failure or part damage (except human factors and force majeure factors), the seller shall be responsible for free repair. The parts need to be replaced will be provide from the seller for free (except the wear-quick part)
b> After the warranty period expired, the buyer only need to pay the actual maintenance cost
c> UNISTAR laser will make return visit of customers at regular time one year
4> We can offer engineers go abroad installation and training , 150USD/One day
Customer offer engineer come and back tickets fees living and eating. Usually it takes 7 days finished training
customer visiting
customer feedback
packing and shipping
FAQ
Q: How do I install and run the machine?
95% of customers can teach themselves.
Q: I don't know which kind of laser cutting machine is suit for me
Q: What should I do if I want to see the condition of the machines in your factory and it is not convenient to go to China?
Q: What's your delivery date?
Q: Do you have CE document and other documents for customs clearance?
