Portable Plasma Cutting Machine

1530 Plasma Cuttting Machine

The gantry CNC plasma/flame cutting machine system can cut any flat shape parts composed of straight lines and arcs. Combination of dynamic and static graphics, easy to learn, can be programmed directly on the machine, can also be drawn on the computer or attached with ready-made CAD files. The presented software is directly converted into G code program files, copied to the operating system through the U disk for automatic cutting. TABLE gantry type double-sided drive structure, the system structure is exquisite, high degree of automation, simple operation, convenient maintenance, high reliability, easy to cut from sheet metal to large thickness steel plate, this product is widely used in various manufacturing metal Plate cutting field. The cutting process can cut carbon steel, stainless steel, alloy steel, aluminum and other non-ferrous metal plates.

This CNC plasma and flame cutting machine is gantry structure with double-driven system, working size can be customized upon requirement.It can be used for cutting carbon steel, stainless steel and non-ferrous metal in any 2d graphics, thus is widely used in metal cutting fields.
This gantry plamsa and oxgen gas cutter can cut mild steel with flame cutting, and cut high carbon steel, stainless steel,aluminum, copper and other nonferrous metal with Plasma cutting; can configurate as you required.,thus it is widely applied in industries such as machinery, automobile, shipbuilding, petro-chemical, war industry, metallurgy, aerospace, boiler and pressure vessel, locomotive etc.

1. The portable gantry cutting machine is an upgraded product of the portable cutting machine. It adopts bilateral drive and has good stability.
2. The machine is cheap and economical, and can realize automatic batch cutting.
3. Install the plasma automatic height controller. During the machine cutting process, the cutting torch can automatically rise and fall according to the unevenness of the steel plate to prevent the cutting torch from crashing, extend the life of the cutting torch, and save costs.
4. The control system has a graphic display function, which can observe the cutting process in real time. And supports 9 languages, it is easier to use your own native language to operate. With power-off memory function, you can continue cutting after the power-on, saving time for cutting from the beginning. There are 48 kinds of graphics, regular graphics can be directly used, change the size, set the quantity, save the computer drawing time and improve efficiency.
5. Using well-known brand stepper motor driver, stable operation and low noise.
6. Equipped with fully automatic nesting software, which saves time for typesetting and improves the utilization rate of steel plates.
7. Optional: remote control, the control distance is 30 meters, the operation is more convenient.
8. Optional: Plasma anti-collision holder, when the torch hits the steel plate, it will automatically stop to prevent the torch from crashing and save costs.
9. Optional: flame automatic ignition, to avoid burning hands when using a lighter to ignite, and to ensure safety.
10. It can be equipped with various power plasma power sources, such as 100A, 130A, 200A, etc, to achieve plasma cutting. The plasma cutting speed is 3-5 times that of flame cutting, which improves production efficiency.

Control system





FASTCAM programming software based on AutoCAD automatic programming and material system.

FASTCAM is designed for all kinds of NC cutter with cutting software, the software can help the user completing various complex parts drawing, programming, material, using convenient, also bring the obvious economic benefit



Cutting head



Flame cutting torch is fixed, plasma cutting torch is mobile type. Flame torch and plasma torch could be changed very easily.

Power supply

Use soft switch inverter technology, to make cutting current very stable; Cutting current rise slowly, reduce consumption of cutting parts; Has a wide adaptability to grid voltage; Unique dust-proof design, high reliability; Compact structure, small volume, light weight, can be installed on many kinds CNC machines;

Motor and Driver

Advantages of stepper motors
‌High-precision control‌: Stepper motors control the rotation angle and speed through precise pulse signals, and the accuracy of each step is usually between 3% and 5%
‌Strong controllability‌: The operation of stepper motors is achieved by controlling pulse current, which can be controlled by software programming
‌High reliability‌: Stepper motors have no brushes, which reduces wear and failure. The life span mainly depends on the life of the bearings, and the maintenance cost is low.
Advantages of drive
‌Wide speed range‌: The speed range of the drive motor is wide, which is suitable for occasions with different speed requirements
‌Large output power‌: The output power of the drive motor is large, which is suitable for occasions requiring high power output.
‌Various drive methods‌: The drive motor can be controlled by inverters, DC power supplies, etc., with high flexibility.
‌



Guide



Taiwan Hiwin guide.Thicker and wider, heavy duty guide rail. Chrome-plated hard light shaft, artisanal casting process of one-time molding, wear-resistant and not easy to deform, the wider and heavier the track cutting more stable





1.Pre-Sales Service:

1)Inquiry and consulting support.
2)We provide you the friendly English user manual and testing video free.
3)24 hours technical support by email or calling.

2.After-Sales Service:

1)Video of operating the machine are available.
2)12 months warranty quality guarantee and charge free technical support forever.
3)Free training to make sure you master the operating of machine.
